Flow meters with float indicator



Series Comments Photos Technical sheet
WITH GLASS TUBE – DTV -Scale ranges :
- water : from 0,1 l/h to 40 m3/h
- air : from 20 Nl/h to 1200 m3/h
- Connection 1/2” to 3” gas female or flange DN 15 to DN 80
- Class 1.
- Model with protection case in PM covered steel or in stainless steel with protection windows in metacrylate or in tempered plate glass.		 PDF
WITH GLASS TUBE LOW FLOW – DTV-F Used in workshop or laboratory, they are equipped with a flow adjusting valve.
- Scale ranges :
- water : from 0,025 l/h to 250 l/h
- air : from 2 Nl/h to 4000 Nl/h
- Class 3.		 PDF
WITH PLASTIC TUBE – DTP -Scale ranges :
- water : from 10 l/h to 40 m3/h
- air : from 160 Nl/h to 1200 Nm3/h
- Connection 1/2” to 3” gaz female or flanges DN 15 to DN 80.
- Class 2,5.		 PDF
WITH METAL TUBE – DTMF For no translucent fluids at pressure up to 400 bar
- Construction in stainless steel.
- Scale ranges :
- water : from 0,6 l/h to 180 m3/h
- air : from 4 Nl/h to 5400 m3/h
- Connection 1/2” à 3/4” gas female or flange DN 15 to DN 150.
- Class 2,5 to 4.		 PDF
